Products Infomation

Camera
Image Sensor : 2 MP CMOS image sensor
Signal System : PAL/NTSC
Frame Rate
PAL: 1080p@25fps
NTSC : 1080p@30fps
Resolution : 1920 (H) ×1080 (V)
Min. illumination : 0.01 Lux @ (F1.2, AGC ON),0 Lux with IR
Shutter Time : 1/25(1/30) s to 1/50,000 s
Lens : 3.6mm, 2.8 mm, 6 mm, 8 mm, 12 mm fixed lens
Horizontal Field of View : 103°(2.8 mm), 82.2°(3.6mm), 54°(6mm), 37.7°(8mm), 24.2°(12 mm)
Lens Mount : M12
Day & Night : IR cut filter
Angle Adjustment : Pan: 0° to 360°, Tilt: 0° to 75°, Rotation: 0° to 360°
Synchronization : Internal synchronization

Menu
AGC : Low/middle/high
Day/Night Mode : Smart/color/BW(Black and White)
Backlight Compensation : Yes
DWDR : Yes
Language : English, Chinese
Functions : Brightness, Sharpness, DNR, Mirror

Interface
Video Output : 1 HD analog output
Switch Button : TVI/AHD/CVI/CVBS

General
Operating Conditions : -40 °C to 60 °C (-40 °F to 140 °F), Humidity: 90% or less (non-condensation)
Power Supply : 12 V DC±15%
Power Consumption : Max. 4 W
Ingress Protection : IP66
Material : Plastic
IR Range : Up to 40 m
Dimension : ?110 mm × 93.2 mm (4.33" × 3.67")
Weight : 350 g (0.77 lb.)
